Bimetal Bandsaw Blade

Bi-metal bandsaw blade, mainly refers to the tooth tip material for high-speed steel or other high-performance steel,saw blade material is low-alloy spring steel metal cutting bandsaw blade.
Material:M42/M51
Function:Cutting Metal
Length:According To Request
Barbed Spacing:26-130mm
Tooth Form:Alternate Tooth

Description

Definition of Bimetal Band Saw Blade

A bimetal band saw blade is a special cutting tool made of two different metal materials via welding. This design allows the bimetal band saw blade to deliver good toughness and fatigue resistance while retaining high hardness and sharpness, making it suitable for efficient and precise cutting of various metal materials.

Application scenarios

Bimetal band saw blades can be used in most scenarios. Bimetal band saw blades with different specifications are compatible with different band saw machines and are suitable for continuous sawing of most types of metals. They can also be used for cutting materials softer than HRC-grade stainless steel.

Bimetal band saw blade to cut

Material: Bimetal band saw blades are made from high-quality steel and other alloys to ensure long service life and excellent cutting performance.

Youto bimetal band saw blades are engineered to deliver smooth, precise cuts, reduce material waste and improve processing efficiency.

Specifications

M42 Bimetal band saw blades list
Specifications *(Width Thickness)**	Teeth Form
13mm*0.65mm	10T 14T 4T 6T 6/10 8/12 10/14
13mm*0.9mm	10T 14T 4T 6T 6/10 8/12 10/14
19mm*0.9mm	6T 8T 10T 14T 3/4 4/6 5/8 6/10 8/12 10/14
27mm*0.9mm	10/14 8/12 6/10 5/8 4/6 3/4 2/3
34mm*1.1mm	8/12 6/10 5/8 4/6 3/4 2/3
41mm*1.3mm	4/6 3/4 2/3 1.7/2.5 1.4/2 1/1.5 0.75/1 0.75/1.25
54mm*1.6mm	3/4 2/3 1.7/2.5 1.4/2 1/1.5 0.75/1 0.75/1.25
67mm*1.6mm	2/3 1.7/2.5 1.4/2 1/1.5 0.75/1 0.75/1.25
80mm*1.6mm	2/3 1.7/2.5 1.4/2 1/1.5 0.75/1 0.75/1.25

M51 Bimetal band saw blades list
Specifications *(Width Thickness)**	Teeth Form
27mm*0.9mm	5/8 4/6 3/4 2/3
34mm*1.1mm	5/8 4/6 3/4 2/3
41mm*1.3mm	4/6 3/4 2/3 1.7/2.5 1.4/2 1/1.5 0.75/1 0.75/1.25
54mm*1.6mm	4/6 3/4 2/3 1.7/2.5 1.4/2 1/1.5 0.75/1 0.75/1.25
67mm*1.6mm	2/3 1.7/2.5 1.4/2 1/1.5 0.75/1 0.75/1.25
80mm*1.6mm	2/3 1.7/2.5 1.4/2 1/1.5 0.75/1 0.75/1.25
